Technical specs
Transmission Output | We guarantee a radius of 150 feet |
---|---|
Frequency Range | 88.0 ~ 108.0 in 0.1 MHz steps |
Frequency Saving | 3 preset buttons |
Pre-emphasis | US and EU Pre-emphasis Options |
Power Options |
• 110/220v AC Wall Adapter • 12/24V DC Mobile Power Adapter • Computer USB Adapter • Internal 3 “AA” Battery Compartment |
Audio-In Options |
• 3.5mm (⅛”) Stereo Jack • RCA Adapter (red/white) • 2.5mm Microphone Port (mic not included) |
Power Control | Mechanical Power Switch |
Frequency Response | 20Hz ~ 15KHz |
Signal to Noise Ratio | >65dB |
Audio Performance | 0.2% distortion |
Stereo Separation | 40dB |
RF Harmonica Rejection | Operation Time |
Antenna Design |
• Reverse-threaded Screw Attachment • 6.5″ Swivel SMA Style Antenna • Interchangeable Wire Extension |
Case Design |
• Sturdy Shell – Secured by exterior screws • Flat bottom is easier to balance • Ergonomic Shape |
Belt Clip |
• Sturdy plastic clip • Easily unscrewed from back • Flat back when removed |
Interface |
• Simplified Controls • Large Screen (1.34″ x 1.10″) • Easy to Read • Blue Backlighting |
Tuning Design | Stable PLL Technology |
Meets FCC Part 15 Rules | Yes, FCC ID: XOA WHFM3 |
Meets Canada IC Rules | Yes, IC ID: 8728A-WHFM3 |
Optional Accessories |
• Desktop Stand • Lavalier Microphone |
Transmission Signal | FM Stereo or FM Mono |
Dimensions | 4.1″ L, 2.7″ W, .9″ D |
Weight | 3.7 ounces (w/ antenna) |
User Manual | Click here to view the User Manual |
